26
Analog Outputs
Point # Description
0 Fwd Voltage Level
1 Fwd Bandwidth
2 Fwd Time Delay
3 Fwd Reactive Compensation
4 Local Voltage Reduction %
5 VRC Stage2
6 Fwd Resistive Compensation
8.2.7 Active
Binary Inputs
Point # Description
0 Tap Pos Known
1 Power Flow Direction
2 Auto Inhibit Status
3 Neutral (U12) Signal
4 Remote Switch position
5 Manual Switch position
Binary Outputs
Point # Description
0 Tap Raise
1 Tap Lower
2 Auto Inhibit (Latch On/Off)
3 Active Auto Inhibit
Analog Inputs
Point # Description
0 Tap Position
1 Load Current
2 Load Voltage
3 KVAR
4 KW
5 Power Factor
6 Band Status Indicators
7 Tap Control Mode
8 Op Count Elapsed
9 CM firmware version
Analog Outputs
Point # Description
0 Fwd Bandwidth
1 Fwd Voltage Level
2 Fwd Time Delay
3 Fwd Resistive Compensation
4 Fwd Reactive Compensation
5 Active Bandwidth
6 Active Voltage Level
7 Active Time Delay
8 Active Resistive Compensation
9 Active Reactive Compensation
10 Active Timer (mins)
