Siemens MJ-4 Series Installation Manual

28
10 SF = 1 VRC1 contacts
11 SF = 1 VRC2 contacts
12 SF = 1 Remote Switch position
13 SF = 1 Manual Switch position
14 SF = 1 Auto Inhibit Out Status
Binary Outputs
Point # Scale Factor Description
0 SF = 1 Tap Raise
1 SF = 1 Tap Lower
2 SF = 1 Auto Inhibit (Latch On/Off)
Analog Inputs
Point # Scale Factor Description
0 Op Count Last Year
1 N/A
2 SF = 1 R/A/M switch position
3 Power Flow Direction Indicator
4 SF = 1 VRC contacts status
5 SF = 1 Band, VRC, VLC status
6 SF = 1 Tap Position
7 SF = 1 Load Current
8 SF= 10 Load Voltage
9 SF= 0.1 Load Voltage (primary)
10 SF= 10 Source Voltage
11 SF= 0.1 Source Voltage (primary)
12 SF = 1 KVA
13 SF = 1 KVAR
14 SF = 1 KW
15 SF= 100 Power Factor
16 SF = 10 P2 Ratio
17 variable Ld Current Dmd (Fwd Present)
18 SF = 1 kVA Dmd (Fwd Present)
19 SF = 1 kVAR Dmd (Fwd Present)
20 SF = 1 kW Dmd (Fwd Present)
21 SF= 10 Load Volts Dmd (Fwd Present)
22 SF= 10 CompVolts Dmd (Fwd Present)
23 variable Load I Dmd (Rev Present) (Amps)
24 SF = 1 kVA Load Dmd (Rev Present)
25 SF = 1 kVAR Load Dmd (Rev Present)
26 SF = 1 kW Load Dmd (Rev Present)
27 SF= 10 Load Volts Dmd (Rev Present) (Volts)
28 SF= 10 Comp Volts Dmd (Rev Present)
29 SF= 10 Max % Boost or Min % Buck (%)
30 SF= 10 Max % Buck or Min % Boost (%)
31 SF= 10 Motor Voltage
32 SF= 10 Vsrc Fwd Dmd
33 SF= 10 Vsrc Rev Dmd
34 SF= 10 Vload dc offset
35 SF= 10 Vload fundamental, RMS
36 SF= 10 Vload 2nd harmonic, RMS
37 SF= 10 Vload 3rd harmonic, RMS
38 SF= 10 Vload 4th harmonic, RMS
39 SF= 10 Vload 5th harmonic, RMS
40 SF= 10 Vload 6th harmonic, RMS
41 SF= 10 Vload 7th harmonic, RMS
42 SF= 10 Vload 8th harmonic, RMS
43 SF= 10 Vload 9th harmonic, RMS
44 SF= 10 Vload 10th harmonic, RMS
