Siemens MOBILETT Plus HP Installation And Setting Instructions

MOBILETT Plus HP SPR8-220.033.03 Page 4 of 12 Siemens-Elema AB
Rev. 02 10.02 SPS-UD Solna, Sweden
2 - 4 Installation and setting
Function check 2
If a maIfunction occurs a message is indicated at the display, see "Service Instructions,
chapter Display messages".
Functional test cable winder 2
• Disconnect the power supply plug.
• Pull the left handle (for the cable winder) upwards.
• Move the cable up and down while rewinding it, in order to avoid any slack, until the cable
is completely rolled up. Check proper function of cable winder and brake.
• Pull out the cable and connect the power supply plug.
Functional tests with motor drive 2
• Test the forward/ reverse and fast (1 m/s) / slow (0.5 m/s) controls.
Speed Adjustment (if necessary) 2
• Remove the plastic plug above and to the left of the supporting wheels on the cover with
the cassette compartment (for details see the Service Instructions).
• Use a screwdriver and adjust the speed by potentiometer on D101:
- turn clockwise (CW) for slower speed.
- turn counterclockwise (CCW) for faster speed.
For adjustment, see chapter "Speed Adjustment".
This will effect the slow/fast speed simultaneously.
NOTE
NOTE

Siemens MOBILETT Plus HP Specifications

General

Brand	Siemens
Model	MOBILETT Plus HP
Category	Medical Equipment
Language	English
