Table 3-2 Special versions
Designation Features Article number
MPP 464 IE H with handheld unit connection HT 8 6FC5303-1AF62-8AD0
with handheld unit connection HT 8, feedrate and spindle override 6FC5303-1AF62-8AC0
The safety-related accessories / spare parts are marked in Section "Accessories and spare parts
(Page 71)" with an *).
3.2 System features
• Industrial Ethernet (transmission rate: 10/100 Mbit/s)
• Function keyboard with 5 x 5 key matrix, can be con󹪝gured and labeled by the user as required
• 8 customer keys (Schlegel) with LEDs, slide-in labels
• 4 extension keys (Schlegel) with LEDs, slide-in labels
• Interfaces for 2 handwheels
• Emergency stop button (4-wire), latching with tamper protection
• Emergency stop override button
• Direct key connection for OP 012
• 1 feedrate override switch
• Free space for 5 extension elements (cutout opening diam. = 22.3 mm)
• Mounting space with blanking cover for EKS identi󹪝cation system
• Free space for a second override switch
System con󹪝guration
The MPP 464 IE H is integrated into the control system in the same way as the MPP 483 IE (see
chapter "System features" in the "MPP 483 IE" manual).
Note
The connection cables are not part of the scope of supply.
3.3 Mechanical design
The MPP 464 IE H Machine Pushbutton Panel consists of:
• Control panel
• Assembled PCB handheld unit connection (FBH HGA)
• Assembled PCB customer keys (FBG KT)
Description
3.3 Mechanical design
Machine Pushbutton Panel: MPP 464 IE H
