Page #49 background image
6.1.5 Universal outputs X53, X54
Universal output X53
Connector designation: X53
Connector type: Male connector, 4-pin
Pin Signal name Type Meaning
1 KT_OUT1 O 24 V output 1 (e.g. lamp for customer key 1)
2 KT_OUT2 O 24 V output 2 (e.g. lamp for customer key 2)
3 KT_OUT3 O 24 V output 3 (e.g. lamp for customer key 3)
4 M V Ground
Universal output X54
Connector designation: X54
Connector type: Male connector, 4-pin
Pin Signal name Type Meaning
1 KT_OUT4 O 24 V output 4 (e.g. lamp for customer key 4)
2 KT_OUT5 O 24 V output 5 (e.g. lamp for customer key 5)
3 KT_OUT6 O 24 V output 6 (e.g. lamp for customer key 6)
4 M V Ground
Technical data for digital outputs
Parameter Value
Voltage
1)
24 V (20.4 V ... 28.4 V)
Maximum load current per output 0.5 A
Maximum load current per connector 1 A
Maximum load current per output at 100% simul‐
taneity of all six outputs
0.15 A
Electrical isolation None
1) Supplied directly via connector X10
6.1.6 Handwheels
Handwheel 1
Connector designation: X60
Connector type: 15-pin D-sub male connector
Connecting
6.1 Pin assignment of the interfaces
Machine Pushbutton Panel: MPP 464 IE H
Equipment Manual, 03/2021, A5E50810237B AA 49
