16 digital inputs can be polled by the X70/X205/DTM connector.
Connector designation: X70/X205/DTM
Connector type: 20-pin male connector
Max. cable length: 0.85 m
Table 6-2 Assignment of connector X70 (MCP, MPP, HAM) / X205 (TCU) / DTM
Pin Name Type Meaning
1 DT1
I
1)
Direct key 1
... ... ...
16 DT16 Direct key 16
17 P5V / CON1
2)
V
+ 5 V input voltage
3)
18 P5V / CON2
2)
+ 5 V input voltage
3)
19 GND Ground
20 GND Ground
1)
The inputs are electrically isolated for MCP / MPP / HAM and DTM.
2)
For the TCU, it is evaluated whether the direct keys have been connected.
3)
Power consumption: 100 mA for MCP / MPP / HAM; 500 mA for DTM
Table 6-3 Signal level
HIGH level: 5 V or open
Low level <= 0.8 V
6.2 General
24 V supply connection
The 24 V supply is connected via a 3-pin terminal block (see 󹪝gure) at connector X1 of the
connection board on the rear of the machine control panel (see 󹪝gure: " Rear side of MPP 464 IE
with interfaces" in Section: "Interfaces" > "Overview").
The protective ground is secured to the M5 bolt.
NOTICE
Damage to the device caused by unfused supply voltages
The 24 V DC power supply must always be grounded and designed as Protective Extra-Low
Voltage (PELV) - protection by functional extra low voltage with safe isolation!
Connecting
6.2 General
Machine Pushbutton Panel: MPP 464 IE H
52 Equipment Manual, 03/2021, A5E50810237B AA
