9.2 Input/output interface of individual wiring
Contact blocks
Table 9-1 Contacts with 󹪞oating outputs S1 to S4 and S7 to S10
AC DC
Rated insulation voltage Ue 50 V 50 V
Rated operating current Ie 2 A
Rated operating current at 24 V Ie 2 A
Min. rated operating current at 5 V I
min
1 mA
Volume resistance < 20 mΩ
Switching capacity 10 Ie 1.1 le
Emergency stop button S13
Rated voltage 24 VDC
Current rating, max. 3 A
Current rating, min. 1 mA
Switching capacity DC 13 according to EN 60947-5-1
Conditional rated short-circuit current 10 A gL/gG according to EN 60947-5-1
B
10d
500 000
Note
The quantitative assessment of the emergency stop safety function must be based on the B
10d
values corresponding to the applied standards (e.g. ISO 13849-1) under consideration of the
respective application (frequency of actuation, operating periods, diagnostics by the evaluation
unit, etc.). The B
10d
values only apply when the technical properties of the emergency stop
button are taken into account.
Emergency stop override S11
Table 9-2 Contacts with 󹪞oating outputs
Utilization category
(EN 60947-5-1)
AC DC
Rated operational voltage Ue 24 V 24 V
Switching capacity
AC-12 le 10 A
AC-15 le 6 A
DC-12 le 10 A
DC-13 le 3 A
Min. rated operating current at 5 V l
min
1 mA
Technical data
9.2 Input/output interface of individual wiring
Machine Pushbutton Panel: MPP 464 IE H
Equipment Manual, 03/2021, A5E50810237B AA 67
