Technical data
9
9.1 MPP 464 IE H
Safety
Safety class according to EN 50178 III; PELV
Degree of protection according to EN 60529
1)
Front: IP54
Rear: IP00
2)
Approvals CE
Flame resistance UL 94 V-1
3)
Electrical data
Overvoltage category Secondary circuit supplied from primary circuits up to Cat. III, 300 VAC
4)
Power supply
5)
24 VDC (20.4 V ... 28.8 V)
Power consumption, max. Assembled PCBs 5 W
Lamp LED 6 W
Handheld unit 13 W
Handwheels 2 x 0.5 W
Total approx. 25 W
Mechanical data
Dimensions W x H x D (mm) 225 x 464 x 154
Overall depth 115 mm
6)
Weight (kg) 3.7
Max. vertical mounting position ≤ 60°
Tightening torques, max. Tension jacks: 0.4 Nm
M3: 0.8 Nm standard
M4: 1.8 Nm
M5: 3 Nm standard
Mechan. stability According to UL 61010
3)
Climatic ambient conditions
Classi󹪝cation of the climatic environment 3K3 according to EN 60721‑3-3
Heat dissipation By natural convection
Condensation and ice formation Not permitted
Supply air Without corrosive gases, dusts and oils
Use and operation
Max. installation altitude Up to 1000 m without derating
From 1000 m to 4000 m with linear ambient temperature derating, -0.5
K per 100 m
Temperature limit values (storage) -20 ... 55° C (cyclic)
Temperature limit values (operation) 0 ... 45° C (front)
0 ... 55° C (rear)
Temperature change Max. 30 K/h
Machine Pushbutton Panel: MPP 464 IE H
Equipment Manual, 03/2021, A5E50810237B AA 65
