Function Upper section
actuator / accessories
Lower section
contact block / indicator light
Installa‐
tion loca‐
tion
Use
Spot LED L5.5K28UW (white) S1 ... S4
S7 ... S10
Keyswitch
Actuating angle 90°
2 positions
*)
Safety lock cylinder 28 mm
∅
RXJSSA 15 E
Key can be removed in
both positions
Contact block AT2 S1 ... S4
S7 ... S10
For S1 1 NC internal, 2 NO +
1 NC external
For S2 ... S4, S7 ... S10 1 NC
internal, 1 NO + 1 NC exter‐
nal
Keys / position se‐
lector
RX-JUWEL 22.3 mm
Schlegel catalog
Contact block AT2 S1 ... S4
S7 ... S10
*) Safety-relevant
Note
When assigning the colors for keys and signaling lights to the corresponding functionality,
observe the standard EN 60204 Part 1 or VDE 0113 Part 1, Chapter Pushbuttons/colors.
Name Description Quantity Article number Installation
location
Override spindle /
rapid traverse
Electronic rotary switch
1x16G, T=24, cap, button,
pointer, dials spindle and rap‐
id traverse
1 6FC5247-0AF12-1AA0 BP12
1)
Override feedrate /
rapid traverse
Electronic rotary switch
1x23G, T=32, cap, button,
pointer, feed and rapid-tra‐
verse dials
1 6FC5247-0AF13-1AA0 BP13
Override feedrate /
rapid traverse
1)
Electronic rotary switch
1x29G, T=32, cap, button,
pointer, feed dials and rapid
traverse
1 6FC5247-0AF14-1AA0 BP12
1)
Emergency stop
22 mm actuating element,
40 mm mushroom pushbut‐
ton, snap action with tamper
protection, latching, red,
with holder, non-illuminated
1 3SU1000-1HB20-0AA0 *) BP01
Contact block 2 NC, exten‐
sion NC EMERGENCY STOP
1 3SU1400-1AA10-1CA0 *) BP01
Commanding and
signaling devices
All extension elements Schlegel or 3SU1 following selection
from Low-Voltage Controls and Distribu‐
tion Catalog (LV 1)
BP20 ... BP23
EKS identication sys‐
tem Euchner
Serial interface EKS-A-ISX-G01-ST09/03 BP17
Interface
PROFIBUS DP
EKS-A-IDX-G01-ST09/03
Spare parts/accessories
10.2 Display elements and operator controls
Machine Pushbutton Panel: MPP 464 IE H
72 Equipment Manual, 03/2021, A5E50810237B AA
