Siemens OpenStage 15 Administration Manual

Administration
A31003-S2000-M102-2-76A9, 28/05/2009
3-122 OpenScape Voice - OpenStage Family, Administration Manual
administration.fm
Speech
3.11.3 Audio Settings
The usage of microphone and speaker for speakerphone mode can be controlled by the ad-
ministrator.
Both microphone and loudspeaker can be switched on or off separately. By default, both mi-
crophone and loudspeaker are switched on.
Administration via WBM
Speech > Audio Settings
Administration via Local Phone
>
The microphone control is not valid for OpenStage 20E, as this model has no built-
in microphone.
|
--- Administration
|
--- Speech
|
--- Audio Settings
|--- Disable microphone
|
--- Disable loudspeech

Siemens OpenStage 15 Specifications

General

Type	IP Phone
Connectivity	Ethernet
Power over Ethernet (PoE)	Yes
Speakerphone	Yes
Keys	Fixed function keys
Headset Port	Yes
Protocols	SIP
Display	Monochrome display
Audio	G.711, G.729
Power Supply	PoE or external power adapter
