Siemens OpenStage 15 Administration Manual

Administration
A31003-S2000-M102-2-76A9, 28/05/2009
3-142 OpenScape Voice - OpenStage Family, Administration Manual
administration.fm
Diagnostics
3.19.4 IP Tests
For network diagnostics, the OpenStage phone can ping any host or network device to deter-
mine whether it is reachable. Additionally, the IP route to a host or network device can be traced
using the traceroute tool contained in the phone software.
The Pre Defined Ping tests provide pinging for a pre-defined selection of servers: SIP server
and SIP registrar.
Ping tests enables the pinging of a random IP address.
The Pre Defined Trace tests provide traceroute tests for a pre-defined selection of servers:
DLS, SIP server, and SIP registrar.
Traceroute enables traceroute tests for a random IP address.
Administration via WBM
Diagnostics > Miscellaneous > IP tests

Siemens OpenStage 15 Specifications

General

Type	IP Phone
Connectivity	Ethernet
Power over Ethernet (PoE)	Yes
Speakerphone	Yes
Keys	Fixed function keys
Headset Port	Yes
Protocols	SIP
Display	Monochrome display
Audio	G.711, G.729
Power Supply	PoE or external power adapter
