Siemens PCA2005-A1 User Manual

Product data
Technical data
5
A6V11571319_en--_b 25 | 34
PCA2005-A1
Technical data for loop, amplifier and loop audio matrix
Maximum number of speaker loops:
Per amplifier channel 2
Loop audio matrix (see Loop audio
matrices [➙ 17])
8
Loop audio matrix (configured as
'Priority only') (see
Loop audio matrices
[➙ 17])
4
Maximum number of loop isolators (100 V) per loop audio matrix (see Loop audio
matrices [➙ 17]):
Per loop 80
All loops 480
Maximum number of loop isolators (100 V) per amplifier output:
1x 150 W (PV2003-A1) 80
1x 200 W (PV1001-A1) 80
1x 250 W (PV2001-A1, PV2007-A1) 80
1x 300 W (PV2003-A1 bridge mode) 80
1x 500 W (PV2001-A1 bridge mode,
PV2002-A1, PV1002-A1)
80
Amplifier power calculation for loop isolator (100 V)
Per loop isolator (100 V) 0.5 W
Maximum audio payload (according to calculation method below):
1
1x 150 W (PV2003-A1) 110 W with 80 loop isolators (100 V)
1x 200 W (PV1001-A1) 160 W with 80 loop isolators (100 V)
1x 250 W (PV2001-A1, PV2007-A1) 210 W with 80 loop isolators (100 V)
1x 300 W (PV2003-A1 bridge mode) 260 W with 80 loop isolators (100 V)
1x 500 W (PV2001-A1 bridge mode,
PV2002-A1, PV1002-A1)
360 W with 80 loop isolators (100 V)
Connections
Design Spring clips
Cable diameter Min.: 0.75 mm
2
Max.: 2.5 mm
2
Loudspeaker cable:
2
Max. cable length per amplifier output 1000 m
Cable types, untwisted only FP30/60 NYM, 2x 1.5 mm
2
ISTY 2 x 2 x 0.8 mm
2
