Product Overview
1.4 Guide for Commissioning of ET 200S with Fail-Safe Modules
ET 200S Distributed I/O System - Fail-Safe Modules
18 Installation and Operating Manual, 08/2008, A5E00103686-07
1.4 Guide for Commissioning of ET 200S with Fail-Safe Modules
Introduction
The following table lists all the important steps required for commissioning ET 200S
distributed I/O systems with fail-safe modules as DP slaves/IO devices on
PROFIBUS DP/PROFINET IO.
Steps from Selecting the F-Modules to Commissioning the ET 200S
Table 1- 3 Steps from Selecting the F-Modules to Commissioning the ET 200S
Step Procedure See ...
1. Select F-modules for ET 200S configuration "Configuring" chapter
2. Configure and assign parameters to F-
modules in
STEP 7
"Configuration and Parameter Assignment"
and "Fail-Safe Modules" chapters
3. Set PROFIsafe addresses on F-modules "Address Assignment and Installation"
chapter
4. Install ET 200S "Address Assignment and Installation"
chapter
5. Wire the ET 200S "Wiring and Fitting Modules" chapter
6. Commission ET 200S on
PROFIBUS DP/PROFINET IO
ET 200S Distributed I/O System
operating
instructions
7. Run diagnostics on ET 200S if
commissioning failed
"Diagnostics" chapter, "Fail-Safe Modules"
chapter and
ET 200S Distributed I/O System
operating instructions
Note
You must configure and assign parameters to the F-modules in
STEP 7
before you start
commissioning.
Reason:
STEP 7
automatically assigns the PROFIsafe addresses to the F-modules. You
must set these PROFIsafe addresses by means of switches on all F-modules prior to their
installation.
