MC-0101
MIXING CHAMBER 2340101
ITEM PART NO. DESCRIPTION QTY.
1 1410002 BEARING 1
2 1414001 BEARING, THRUST 1
3 1419001 BEARING, FLANGE CARRIER 1
4 2124002 CAP, TOP, MIXING CHAMBER 1
5 2124003 CAP, BOTTOM, MIXING CHAMBER 1
6 2650001 COLLAR, 1/2" I.D. 1
7 2650002 COLLAR, 3/4" I.D. 2
8 5173304 IMPELLER 1
9 5173305 IMPELLER, SECONDARY 1
10 5551002 LABEL - DISCHARGE 1
11 6020031 NUT, HEX HD., 1/4"-20 12
12 6023031 NUT, ACORN, 1/4"-20, S.S. 4
13 6091801 O-RING 2
14 6676002 PLATE, BAFFLE 1
15 7071201 PULLEY 1
16 7772216 SCREW, 10-32 X 1" 2
17 7772506 SCREW, 10-32 X 3/8" 1
18 7802910 SEAL, MECHANICAL 1
19 7854303 SHAFT, IMPELLER 1
20* 8140005 SPACER ROD 2
21 8143011 SPACER 2
22 8603002 STUD 2
23 8603004 ROD 4
24 9412606 TUBE, ACRYLIC 1
25 9572304 VALVE, INJ. CHECK 1
26 9740300 WASHER, FLAT, 1/4" 9
27 8143010 SPACER 1
*Factory personnel identify item #20 as part RM6600021, which must be cut to a
length of 6-3/4 inches. For replacements, request P/N 8140005 to receive spacer
rods, which are pre-cut to the appropriate length.
