Siemens QMX3.P30 - HVAC Operation and Display; Operation and Display: Relative Humidity Visualization; 5.5.10 Display on QMX3.P70 Air Quality Indication LED

39 / 46
Siemens Wall-mounted sensors and room operator units for KNX/ETS and KNX/ACS CM2N1602en_05
Building Technologies ETS engineering 2018-09-14
Designation
Values
Type
Visible parameter name in ETS Range
(Default)
Unit
QMX3.P30
QMX3.P40
QMX3.P70
QMX3.P34
QMX3.P74
QMX3.P37
QMX3.P02
5.5.8 HVAC operation and display
Display Temperature visualization -----
(Room)
Outside
Room and Outside
X X X
Operation Room temperature setpoint
yes; (no)
X
X
X
Room temperature setpoint type
Absolute; (
Relative
)
X
X
X
Lower limit temp.setp.abs.
5…21 (18)
°C
X
X
X
Upper limit temp. Setp. Abs. 21…40 (26) °C
X
X
X
Temp.setp.op.in steps of
0.1; 0.2; 0.5; 1.0; 2.0 (0.1)
°C
X
X
X
Max. negative temp.shift -10…0 (-3) K
X
X
X
Max. positive temp.shift
0…+10 (+3)
K
X
X
X
Temperature shift in steps of
0.1; 0.2; 0.5; 1.0; 2.0 (0.5)
K
X
X
X
Operation Room Operating Mode yes; (no)
X
X
X
Operation Room Occupancy Mode
(yes); no
X
X
X
Display Window state visualization yes; (no)
X
X
X
Display Heating/Cooling indication
yes; (no)
X
X
X
Operation fan Speed
yes; (no)
X
X
X
Fan type 1-speed
(3-speed)
Variable speed
X X X
Minimum fan speed (variable speed) 0…100 (0%) %
X
X
X
Maximum fan speed (variable speed)
100…0 (100%)
%
X
X
X
R
egardless of whether the "Display Window state” is set to "Yes" or "No", all 4
communication objects for window contacts are always displayed
5.5.9 Operation and display: Relative humidity visualization
Display: Relative humidity visualization
-----
(Room)
O
utside
Room and Outside
X X X
Min. rel. humidity setp. (%r.h.) 0…99 (10%) %r.h.
X
X
X
Max. rel. humidity setp. (%r.h.)
1…100 (95%
%r.h.
X
X
X
Rel. Hum. operation in steps of
1;2;5;10;20 (1%)
%
X
X
X
5.5.10 Display on QMX3.P70 Air quality indication LED
Change color green <--> yellow at (ppm)
400.2000 (1000)
ppm
X
Change color yellow <--> red at (ppm)
400…2000 (1500)
ppm
X
Bus influence
(No)
Can be de-/activated via bus
X
Note
