MAN-100472RD150 - Operating Instructions
57030-EN-180717
Ambient conditions
Storage and transport temperature
-40 … +80 °C (-40 … +176 °F)
Ambient temperature
Ʋ without display and adjustment
module
-40 … +80 °C (-40 … +176 °F)
Ʋ With display and adjustment module -20 … +70 °C (-4 … +158 °F)
Process conditions
Vibration resistance
4gat5…200HzaccordingtoEN60068-2-6(vibration
with resonance)
Vibration resistance with carrier rail
mounting
1gat5…200HzaccordingtoEN60068-2-6(vibration
with resonance)
Shock resistance
100 g, 6 ms according to EN 60068-2-27 (mechanical
shock)
Electromechanical data
Options of the cable entry
Ʋ Cable entry M20 x 1.5, ½ NPT
Ʋ Cable gland M20 x 1.5, ½ NPT
Ʋ Blind plug M20 x 1.5; ½ NPT
Ʋ Closing cap ½ NPT
Connection terminals
Ʋ Type Spring-loaded terminal
Ʋ Stripping length 8 mm
Wire cross-section of the connection cable (according to IEC 60228)
Ʋ Massive wire, stranded wire 0.2 … 2.5 mm² (AWG 24 … 14)
Ʋ Stranded wire with end sleeve 0.2 … 1.5 mm² (AWG 24 … 16)
Electromechanical data - Panel mounting
Terminals, plug connector
Ʋ Type Spring-loaded terminal
Ʋ Stripping length 8 mm
Wire cross-section of the connection cable (according to IEC 60228)
Ʋ Massive wire, stranded wire 0.2 … 1.5 mm² (AWG 24 … 16)
Ʋ Stranded wire with end sleeve 0.25 … 0.75 mm² (AWG 24 … 18)
Electrical protective measures
Protection rating
Ʋ Plastic housing IEC 60529 IP 66/IP 67, NEMA Type 4X
Ʋ Housing for panel mounting (mount-
ed)
IEC 60529 IP 40, NEMA Type 1
Ʋ Aluminium/Stainless steel housing IEC 60529IP 66/IP 68 (0.2 bar), NEMA Type 6P
