MAN-100472 RD150 - Operating Instructions
57030-EN-180717
7 Setup via PACTware
7.1 Connect the PC
The PC is connected via the interface adapter to the device.
Parameter adjustment options:
•
RD150
•
Sensor
3
1
2
Fig. 18: Connection of the PC via interface adapter
1 USB cable to the PC
2 Interface adapter
3 RD150
The PC is connected via a HART modem to the sensor side of the
RD150.
Parameter adjustment options:
•
Sensor
Via interface adapter
Via HART modem
