Siemens RD150

42
MAN-100472RD150 - Operating Instructions
57030-EN-180717
10.3 Dimensions
RD150, plastic housing
ø 77 mm
(3.03")
~ 69 mm
(2.72")
86 mm
(3.39")
82 mm
(3.23")
97 mm
(3.82")
6,5 mm
(0.26")
97 mm
(3.82")
Fig. 21: RD150 with plastic housing
RD150, plastic housing (panel mounting)
72,5 mm
(2.85")
72,5 mm
(2.85")
78,2 mm
(3.08")
22,5 mm
(0.89")
70 mm
(2.76")
77 mm
(3.03")
67 mm
(2.64")
56 mm
(2.20")
76 mm
(2.99")
Fig. 22: RD150 with plastic housing for panel mounting
