Communication
Control parameters
8
34
| 52 A6V11917618_en--_b
Parameter
Name
Factory setting
Range
P06
Economy heating setpoint
15 °C
10…40 °C
P07
Economy cooling setpoint
30 °C
10…50 °C
P08
P-band Xp/switching diff
10 K
-
P09
Integral action time Tn
300 s
-
P10
Hysteresis (ΔT)
1 K
Controller
hysteresis
P11
Delay from Comfort to Standby
0 min
-
P12
Delay from Standby to Comfort
0 min
-
P13
Input AI
0 = no function
0 = no function
1 = Room temp
ext. sensor
11= Supply air
temperature
limitation sensor
P14
Input UI
0 = no function
0 = no function
1 = Changeover
digital
2 = Changeover
analog
3 = OFF mode
(open window)
P15
Type of digital actuator
0 = PWM
0 = PWM
1 = 3-position
2 = On/Off
P16
Output AO1
0 = 0…10 V
0 = 0…10 V
1 = 2…10 V
2 = 10…2 V
3 = 10…0 V
P17
Output AO2
0 = 0…10 V
0 = 0…10 V
1 = 2…10 V
2 = 10…2 V
3 = 10…0 V
P18
PWM algorithm cycle heating
60 s
-
P19
PWM algorithm cycle cooling
60 s
-
P20
Actuator running time (3-
position) heating
120 s
-
P21
Actuator running time (3-
position) cooling
120 s
-
P22
Time (in hours) between
exercise of heating actuator
23 h
-
P23
Time (in hours) between
exercise of cooling actuator
23 h
-
