4.3.5 Chilled ceiling with radiator
For chilled ceiling with radiator, set the corresponding basic application and
disable the fan via parameter P25.
The following applications are available:
Application for
chilled / heated
ceiling, radiator
Set basic
application
Refer to chapter
Sequences
Chilled / heated
ceiling with
changeover
2-pip
2-pipe fan coil
unit [➙ 15]
Chilled / heated
ceiling & el heater
2-pipe with
electric heater
2-pipe fan coil
unit with electric
heater [➙ 16]
Chilled ceiling
with radiator
4-pipe
4-pipe fan coil
unit [➙ 17]
4.3.6 Setpoint and sequences
2-pipe applications
In changeover applications, the Comfort setpoints (W) for the heating and
cooling sequence are the same.
In 2-pipe applications with electric heater, the Comfort setpoint is either in the
first heating sequence (in heating mode) or in the cooling sequence (in cooling
mode).
The setpoints for Standby (Economy) mode and Protection mode are below the
Comfort setpoint for heating and above the Comfort setpoint for cooling.
The heating and cooling setpoints for Standby (Economy) mode can be set via
parameters P06 and P07.
Application
Comfort mode
Standby (Economy) mode
Heating
Cooling
Heating
Cooling
2-pipe
2-pipe &
electric heater
W
Setpoint for Comfort mode P64
W
HeatEco
t
Heating setpoint for Standby (Economy) mode, P06
W
CoolEco/
Cooling setpoint for Standby (Economy) mode, P07
E1
Electric heater sequence
T
W
Y
T
W
Y
T
W
HeatEco
Y
T
Y
W
CoolEco
W
Y
2)
E1
T
W
Y
E1
1)
T
W
HeatEco
Y
E1
2)
T
Y
W
CoolEco
E1
1)
T
W
HeatEco
