Siemens RDB160BN - Inputs and Communication Interfaces

Overview
2
8
| 52 A6V11917618_en--_b
Inputs
● One analog input for:
– External room temperature or return air temperature sensor
– Supply air temperature limitation sensor
● One universal input for:
– Changeover digital
– Changeover analog
– Window contact
● One digital input
– Presence input
– Window contact
BACnet MS/TP communication
Device address
The BACnet MS/TP MAC address can be set from 0 to 127.
Factory setting is from 0 to 99.
Baud rate
The baud rate is selectable. Four options are available for the RDB160BN:
9600, 19200, 38400 and 76800 (default setting) bps.
The RDB160BN BACnet MS/TP room thermostats are delivered with a fixed set
of applications and related parameters.
The relevant application is selected and activated during commissioning using
the local HMI or the BACnet MS/TP commissioning tools.
For detailed information about the applications, please refer to chapter
'Applications'.
