Siemens RDG20 KN Series User Manual

Technical data
7
A6V11545892_en--_e
181 | 186
Standards and directives
RCM conformity
A5W00120121A
*
Protection class
II as per EN 60730
Pollution class
Normal
Degree of protection of housing
IP30 as per EN 60529
Eco design and labeling directives
Based on EU directive 813/2013 (Eco design directive)
and 811/2013 (Labelling directive) concerning space
heaters, combination heaters, the following classes
apply:
RDG20..
● Application with On/Off operation of a heater
● PWM (TPI) room thermostat, for use with On/Off
output heaters
Class I value 1 %
Class IV value 2 %
RDG26..
● Application with On/Off operation of a heater
● PWM (TPI) room thermostat, for use with On/Off
output heaters
Class I value 1 %
Class IV value 2 %
Meets the requirements for eu.bac certification (RDG2..KN)
See product list at: http://www.eubaccert.eu/licences-by-criteria.asp
Application
Device
Actuator outputs
CA value (K)
License No.
Fan coil units (2 pipes)
Variable speed fan
RDG20..KN
Thermal actuator
Heating 0.4
Cooling 0.3
220019
RDG26..KN
Motorized DC
Heating 0.1
Cooling 0.1
220020
Fan coil units (2 pipes,2 wires)
Variable speed fan
RDG20..KN
Thermal actuator
Heating 0.1
Cooling 0.3
220019
RDG26..KN
Motorized DC
Heating 0.1
Cooling 0.1
220020
Fan coil units (4 pipes)
Variable speed fan
RDG20..KN
Thermal actuator
Heating 0.4
Cooling 0.3
220019
RDG26..KN
Motorized DC
Heating 0.1
Cooling 0.1
220020
Ceiling systems
RDG26..KN
Motorized DC
Heating 0.2
Cooling 0.2
220020
6-port control
ball valves
VWG41.10...
Heating 0.2
Cooling 0.4
220020
6-port control
ball valves
VWG41.20...
Heating 0.2
Cooling 0.4
220020
