Siemens RDG20 KN Series User Manual

Functions
Additional functions
4
A6V11545892_en--_e
51 | 186
Presence detection is also possible via bus (RDG2..KN). In this case, do not
assign the function to any local input X1, X2 or U1.
Time schedule via
bus (RDG2..KN)
Presence detector behavior
Comfort mode
When the presence detector is activated or deactivated, the
operating mode remains in Comfort.
Economy mode
● When the presence detector is activated, the operating
mode changes to Comfort.
● When the presence detector is deactivated, the
operating mode changes to Economy (Auto).
Protection mode
Presence detection has no influence on the operating
mode.
Not available
● When the presence detector is activated, the operating
mode changes to Comfort.
● When the presence detector is deactivated, the
operating mode changes to previous operating mode.
If a room is unoccupied, the operating mode changes to Economy. This overrides
the operating mode on the thermostat. The buttons are locked and symbol is
displayed. An occupied room sets the thermostat back to the previous operating
mode. Use a card reader and not a motion detector combined with hotel presence
function for hotel applications, as the buttons are locked in case of unoccupancy.
Hotel presence detection is also possible via bus (RDG2..KN). In this case, do not
assign the function to local input X1, X2 or U1.
Time schedule via
Bus (RDG2..KN)
Presence detector behavior
Comfort mode
When hotel guests leave their rooms (room is unoccupied),
the operating mode changes to Economy. The buttons are
locked and symbol is displayed.
Economy mode
● When hotel guests leave their rooms (room is
unoccupied), the operating mode changes to Economy.
The buttons are locked and symbol is displayed.
● When the room is occupied, the operating mode
changes to the previous operating mode.
Protection mode
Presence detection has no influence on the operating
mode.
Not available
● When hotel guests leave their rooms (room is
unoccupied), the operating mode changes to Economy.
The buttons are locked and symbol is displayed.
● When a room is occupied, the operating mode changes
to the previous operating mode.
● When the schedule changes to Economy but the presence detector is still
active, the operating mode remains in Comfort mode until the presence
detector becomes inactive.
● The contact (e.g., a card reader) can be connected to multifunctional input X1,
X2 or U1 (set P150, P153 or P155 to 10) or occupancy is sent via bus from a
KNX presence detector (only one input source must be used, either local input
X1/X2/U1 or KNX bus).
Hotel presence mode
(Input: P150 / P153 /
P155 = 13)
Notes
