4.12.1 Parameters of the "Service level"
Parameter
Name
Factory setting Range
RDG400
P01 Control sequence 1 = cooling only 0 = heating only
1 = cooling only
2 = H/C changeover manually
3 = H/C changeover automatically
ü
P02 Operating mode profile (operating mode
button)
1 1 = Comfort – Protection
2 = Comfort - Economy - Protection
ü
P04 Selection of °C or °F 0 (°C) 0 = degrees Celsius (°C)
1 = degrees Fahrenheit (°F)
ü
P05 Sensor calibration (internally, externally) 0 K (0 °F) – 3...3 K (– 6...6 °F)
ü
P06 Standard temperature display 0 0 = room temperature
1 = setpoint
ü
P07 Display info line
(2nd line of LCD)
0 0 = --- (no display)
1 = °C and °F
0..1
P08 Comfort setpoint 21 °C (70 °F) 5...40 °C (41...104 °F)
ü
P09 Min. setpoint for Comfort mode 5 °C (41 °F) 5...40 °C (41...104 °F)
ü
P10 Max. setpoint for Comfort mode 35 °C (95 °F) 5...40 °C (41...104 °F)
ü
P11 Economy heating setpoint 15 °C (59 °F) OFF, 5 °C (41 °F) ...WcoolE-saving;
(WcoolE-saving = 40 °C (104 °F) max.)
ü
P12 Economy cooling setpoint 30 °C (86 °F) OFF, WHeatEco...40 °C (104 °F);
(WHeatEco = 5 °C (41 °F) min.)
ü
P14 Button lock function 0 0 = unlocked
1 = auto locked
2 = manual locked
ü
ü Parameter available
· Parameter display depends on selected application and function
· P01 is available for "Single-duct" and "Single duct & heating/cooling coil" only
