36/44
Siemens RDG400 Basic Documentation CE1P3182en
Building Technologies 2015-05-20
1
2
4
5
6
6
7
8 10
11
1213
14
16
3
1517
1
Heating mode 10 Confirmation of parameters
2
Electric heater active 11
Degrees Celsius
Degrees Fahrenheit
3
Cooling mode 12 Digits for room temperature and setpoint
4
Comfort mode 13 Button lock active
5
Economy mode 14 Condensation in room (dewpoint sensor active)
6
Protection 15 Fault
7
Escape 16
Temporary timer function (visible when
operating mode is temporarily extended
presence or absence)
8
Digits for room temperature, setpoint,
etc.
17 Indicates that room temperature is displayed
5.3 Disposal
The devices are considered electronics devices for disposal in terms of European
Directive 2012/19/EU and may not be disposed of as domestic waste.
· Dispose of the device via the channels provided for this purpose.
· Comply with all local and currently applicable laws and regulations.
LCD
