4.12.3 Diagnostics and tests
Parameter
Name
Factory setting Range
RDG400 Diagnostics and test
d01 Application type Diagnostics 0 = (no application)
1 = Single-duct
2 = Single-duct with electric heater
3 = Single-duct with radiator/floor heating
4 = Single-duct with H/C coil
ü
d02 X1 status Diagnostics 0 = not activated (for DI)
1 = Activated (DI)
0…49 °C = Curr. temp. value (for AI)
00 = H/C input closed
100 = H/C input open
ü
d03 X2 status Diagnostics 0 = not activated (for DI)
1 = Activated (DI)
0…49 °C = Curr. temp. value (for AI)
00 = H/C input closed
100 = H/C input open
ü
d04 D1 status Diagnostics 0 = not activated (for DI)
1 = Activated (DI)
00 = H/C input closed
100 = H/C input open
ü
d05 Test mode for checking
actuator direction Y1/Y2
(press left button to escape)
--- "---" = no signal at outputs Y1 and Y2
OPE = output Y1 forced opening
ü
