Chapter 6
Certification
RUGGEDCOM RMC30
Installation Guide
26 EMC and Environmental Type Tests
Test Description Test Levels Severity Levels
1000 A/m for 1 s 5
DC Power Ports 30% for 0.1 s, 60% for
0.1 s, 100% for 0.05 s
IEC 61000-4-29
30% for 1 period, 60% for 50 periods
IEC 61000-4-11
Voltage Dips and Interrupts
AC Power Ports
100% for 5 periods,
100% for 50 periods
Signal Ports 2 kV (Fail-Safe Relay output)
DC Power Ports 1.5 kV
Dielectric Strength
AC Power Ports 2 kV
Signal Ports 5 kV (Fail-Safe Relay Output)
DC Power Ports 5 kV
IEC 60255-5
HV Impulse
AC Power Ports 5 kV
a
Siemens specified severity level.
IEEE 1613 EMC Immunity Type Tests
NOTE
The RUGGEDCOM RMC30 meets Class 2 requirements for an all-fiber configuration and Class 1
requirements for copper ports.
Description Test Levels
Enclosure Contact ± 8 kVESD
Enclosure Air ± 15 kV
Radiated RFI Enclosure Ports 35 V/m
Signal Ports ± 4 kV @ 2.5 kHz
DC Power Ports ± 4 kV
AC Power Ports ± 4 kV
Fast Transient
Earth Ground Ports ± 4 kV
Signal Ports 2.5 kV common mode @ 1MHz
DC Power Ports 2.5 kV common, 1 kV differential mode @ 1MHz
Oscillatory
AC Power Ports 2.5 kV common, 1 kV differential mode @ 1MHz
Signal Ports 5 kV (Failsafe Relay)
DC Power Ports 5 kV
HV Impulse
AC Power Ports 5 kV
Signal Ports 2 kV
DC Power Ports 1.5 kV
Dielectric Strength
AC Power Ports 2 kV
