Chapter 6
Certification
RUGGEDCOM RS8000T
Installation Guide
28 EMC and Environmental Type Tests
Test Description Test Levels Severity Levels
IEC 61000-4-3 Radiated RFI Enclosure ports 20 V/m x
Signal ports ±4 kV @ 2.5 kHz x
DC Power ports ±4 kV 4
AC Power ports ±4 kV 4
IEC 61000-4-4 Burst (Fast Transient)
Earth
ground ports
±4 kV 4
Signal ports ±4 kV line-to-earth, ±2 kV line-to-line 4
DC Power ports ±2 kV line-to-earth, ±1 kV line-to-line 3
IEC 61000-4-5 Surge
AC Power ports ±4 kV line-to-earth, ±2 kV line-to-line 4
Signal ports 10 V 3
DC Power ports 10 V 3
AC Power ports 10 V 3
IEC 61000-4-6 Induced (Conducted) RFI
Earth
ground ports
10 V 3
IEC 61000-4-8 Magnetic Field Enclosure ports 40 A/m continuous, 1000 A/m for 1 s
DC Power ports 30% for 0.1 s, 60% for
0.1 s, 100% for 0.05 s
IEC 61000-4-29
30% for 1 period, 60% for 50 periods
IEC 61000-4-11
Voltage Dips and Interrupts
AC Power ports
100% for 5 periods,
100% for 50 periods
Signal ports 2.5 kV common, 1 kV
differential mode @ 1 MHz
3
DC Power ports 2.5 kV common, 1 kV
differential mode @ 1 MHz
3
IEC 61000-4-12 Damped Oscillatory
AC Power ports 2.5 kV common, 1 kV
differential mode @ 1 MHz
3
Signal ports 30 V Continuous, 300 V for 1 s 4IEC 61000-4-16 Mains Frequency Voltage
DC Power ports 30 V Continuous, 300 V for 1 s 4
IEC 61000-4-17 Ripple on DC Power Supply DC Power ports 10% 3
Signal ports 2 kVAC (Fail-Safe Relay output)
DC Power ports 1.5 kVDC
Dielectric Strength
AC Power ports 2 kVDC
Signal ports 5 kV (Fail-Safe Relay Output)
DC Power ports 5 kV
IEC 60255-5
HV Impulse
AC Power ports 5 kV
