RUGGEDCOM RS8000T
Installation Guide
Chapter 6
Certification
EMC and Environmental Type Tests 29
IEEE 1613 (C37.90.x) EMC Immunity Type Tests
NOTE
The RUGGEDCOM RS8000T meets Class 2 requirements for an all-fiber configuration and Class 1
requirements for copper ports.
IEEE Test IEEE 1613 Clause Description Test Levels
Enclosure Contact ±8 kVC37.90.3 9 ESD
Enclosure Air ±15 kV
C37.90.2 8 Radiated RFI Enclosure ports 35 V/m
Signal ports ±4 kV @ 2.5 kHz
DC Power ports ±4 kV
AC Power ports ±4 kV
Fast Transient
Earth ground ports ±4 kV
Signal ports 2.5 kV common mode @ 1MHz
DC Power ports 2.5 kV common and
differential mode @ 1MHz
C37.90.1 7
Oscillatory
AC Power ports 2.5 kV common and
differential mode @ 1MHz
Signal ports 5 kV (Failsafe Relay)
DC Power ports 5 kV
HV Impulse
AC Power ports 5 kV
Signal ports 2 kVAC (Failsafe Relay)
DC Power ports 1.5 kVDC
C37.90 6
Dielectric
Strength
AC Power ports 2 kVAC
Environmental Type Tests
Test Description Test Levels Severity Levels
IEC 60068-2-1 Cold Temperature Test Ad -40 °C (-40 °F), 16 Hours
IEC 60068-2-2 Dry Heat Test Bd 85 °C (185 °F), 16 Hours
IEC 60068-2-30 Humidity (Damp
Heat, Cyclic)
Test Db 95% (non-condensing),
55 °C (131 °F), 6 cycles
IEC 60255-21-1 Vibration 2 g @ 10-150 Hz Class 2
IEC 60255-21-2 Shock 30 g @ 11 ms Class 2
