Chapter 2
Installing the Device
RUGGEDCOM RS900
Installation Guide
8 Mounting the Device on a DIN Rail
IMPORTANT!
Heat generated by the device is channeled outwards from the enclosure. As such, it is recommended
that 2.5 cm (1 in) of space be maintained on all open sides of the device to allow for some
convectional airflow.
Forced airflow is not required. However, any increase in airflow will result in a reduction of ambient
temperature and improve the long-term reliability of all equipment mounted in the rack space.
NOTE
For detailed dimensions of the device with either DIN rail or panel hardware installed, refer to
Section5.7, “Dimension Drawings”.
CONTENTS
• Section2.4.1, “Mounting the Device on a DIN Rail”
• Section2.4.2, “Mounting the Device to a Panel”
Section2.4.1
Mounting the Device on a DIN Rail
For DIN rail installations, the RS900 can be equipped with a DIN rail bracket pre-installed on the back of the
chassis. The bracket allows the device to be slid or clipped onto a standard 35 mm (1.4 in) DIN rail.
To mount the device to a DIN rail, do the following:
1. Align the slot in the bracket with the DIN rail.
