Page #46 background image
Certification
6.2EMC and Environmental Type Tests
Test Description Test Levels Severi-
ty Levels
IEC
61000-4-9
Pulse Magnetic Field Enclo-
sure Ports
300 A/m 4
IEC
61000-4-11
Voltage Dips and Interrupts AC Pow-
er Ports
30% for 0.5 Cycles
60% for 5 Cycles
100% for 250 Cycles
Signal Ports 30 V Continuous
300 V for 1 s
4IEC
61000-4-16
Mains Frequency Voltage
DC Pow-
er Ports
30 V Continuous
300 V for 1 s
4
IEC
61000-4-17
Ripple on DC Power Supply DC Pow-
er Ports
15% 4
IEC
61000-4-18
Damped Oscillatory Wave Slow
Damped
2.5 kV Common
100 kHz or 1 MHz
3
IEC
61000-4-29
Voltage Dips and Interrupts DC Pow-
er Ports
30% for 0.1 s
60% for 0.1 s
100% for 0.05 s
Signal Ports 2 kV (Failsafe Relay Output)
DC Pow-
er Ports
2 kV or 2.8kV DC
Dielectric Strength
AC Pow-
er Ports
2 kV
Signal Ports 5 kV (Failsafe Relay Output)
DC Pow-
er Ports
5 kV
IEC
60255-27
HV Impulse
AC Pow-
er Ports
5 kV
EMC Immunity Type Tests per IEEE 1613
Note
The RUGGEDCOM RSG910C meets Class 2 requirements for an all-fiber configuration
and Class 1 requirements for copper ports. Class 1 allows for temporary communica-
tion loss, while Class 2 requires error-free and interrupted communications.
Test Description Test Levels
Enclosure Contact ± 8 kVIEEE 1613 ESD
Enclosure Air ± 15 kV
IEEE 1613 Radiated RFI Enclosure Ports 35 V/m
Signal Ports ± 4 kV @ 2.5 kHz, 5 kHz
DC Power Ports ± 4 kV @ 2.5 kHz, 5 kHz
AC Power Ports ± 4 kV @ 2.5 kHz, 5 kHz
IEEE 1613 Fast Tran-
sient
Earth Ground Ports ± 4 kV
RUGGEDCOM RSG910C
Installation Manual, 02/2020, C79000-G8976-1405-06
37
