36 EMC and Environmental Type Tests
Description Test Levels
AC Power ports +/- 4 kV
Earth ground ports +/- 4 kV
Signal ports 2.5 kV common mode @1 MHz
DC Power ports 2.5 kV common, 1 kV differential mode @ 1 MHz
Oscillatory
AC Power ports 2.5 kV common, 1 kV differential mode @ 1 MHz
Signal ports 5 kV (Fail-Safe Relay output)
DC Power ports 5 kV
HV Impulse
AC Power ports 5 kV
Signal ports 2 kV
DC Power ports 2 kV
Dielectric Strength
AC Power ports 2 kV
Environmental Type Tests
Test Description Test Levels
IEC 60068-2-1 Cold Temperature Test Ad -40 °C (-40 °F), 16 Hours
IEC 60068-2-2 Dry Heat Test Bd 85 °C (185 °F), 16 Hours
IEC 60068-2-30 Humidity (Damp Heat, Cyclic) Test Db 95% (non-condensing), 55 °C (131 °F), 6 cycles
IEC 60255-21-1 Vibration 2 g @ 10 - 150 Hz
IEC 60255-21-2 Shock 30 g @ 11 mS
