Siemens S7 Series User Manual

4 Configuration and Project Engineering
Communication with S7 CPU via KNX Gateway
Entry ID: 109739689, V1.0, 06/2017
21
 Siemens AG 2017 All rights reserved
4.4.4 “eib1.txt” gateway file
The data points of the KNX protocol and their properties are defined in the
“eib1.txt” configuration file.
Table 4-6: Structure of the “eib1.txt” gateway file
No.
Description
Comment
1.
The KNX data points have the following
structure:
[<def> <group address>]
name = <name>
format = <format>
<def>:For the definition of data points, see
Table 3-1: Definition of the data point types
<group address>: Two- or three-digit
KNX group address.
Two-digit: <maj>/<min>
Three-digit: <maj>/<mid>/<ext>
<maj>: 0-31
<min>: 0-2047
<mid>: 0-7
<ext>: 0-255
<name>: Optional; you can specify plain text
for the data point.
<format>: Protocol-dependent properties of
the data point such as the data point for
interpreting the information stored at the
address.
If necessary, more parameters can be added
to the format, for example the poll rate (here:
P:10 for read value every 10 seconds):
format = <format> [F:<fact>]
[P:<poll>][U:<upd>] [I:<opt>]
[L:<loc>] [H:<prio>] [R:<addr>]
[D:<dly>]
For more driver-specific information such as
type, address, formats and other parameters,
please refer to the online documentation
provided by MBS at the following link:
http://wiki.mbs-
software.info/doku.php?id=eib_knx
[M failure]
name = EIB Failure
[M 1/1/1]
name = KNX-->S7 value
format = SINT16
[S 1/1/2]
name = S7-->KNX value
format = SINT16
[M 1/1/3]
name = KNX-->S7 switch
format = UINT1
[S 1/1/4]
name = S7-->KNX statusLED
format = UINT1
[X 1/1/5]
name = KNX-->S7 temperature
format = SFLOAT P:10
Note
For the driver to be provided with current values for all data points when starting
up the gateway, all data points defined in the driver must have the read flag set
on the ETS side.

Siemens S7 Series Specifications

General

CPU	Varies by model (e.g., S7-300, S7-400, S7-1200, S7-1500)
Memory	Varies by model (e.g., 64 KB to 20 MB)
Communication Interfaces	PROFINET, PROFIBUS, Ethernet, MPI
I/O Modules	Digital Input (DI), Digital Output (DO), Analog Input (AI), Analog Output (AO)
Programming	STEP 7 (TIA Portal) programming software. Supports various programming languages and provides tools for configuration, diagnostics, and commissioning.
Power Supply	24 V DC, 120/230 V AC. Integrated or external power supply, depending on the CPU and system configuration.
Operating Temperature	Typically 0 to 60 °C (horizontal mounting), -20 to 60°C (vertical mounting), depending on the specific module.
Product Type Designation	S7-300, S7-400, S7-1200, S7-1500
Programming Languages	LAD, FBD, STL, SCL, GRAPH
Digital Inputs	Varies by module (e.g., 8, 16, 32 channels)
Digital Outputs	Varies by module (e.g., 8, 16, 32 channels)
Analog Inputs	Varies by module (e.g., 2, 4, 8 channels)
Analog Outputs	Varies by module (e.g., 2, 4, 8 channels)
Operating Voltage	24V DC or 120/230V AC (varies by model)
CPU Processing Speed	Varies by model (e.g., 0.1 ms to 5 ns per instruction)
Real-time Clock	Integrated (varies by model)
Mounting Type	DIN rail mounting.
Protection Class	IP20
