2 Solution
Communication with S7 CPU via KNX Gateway
Entry ID: 109739689, V1.0, 06/2017
9
 Siemens AG 2017 All rights reserved
Software components
Table 2-4: Software components
Component
No.
Article number
Note
SIMATIC STEP 7
Professional V14 (TIA
Portal)
1
6ES7822-1..04-..
-
GSDML-V2.31-MBS-
MICRO3004-20150206
1
Manufacturer: MBS
GmbH
The latest GSDML files are
available directly from MBS
GmbH.
The GSDMLV2.31 file was
used in this example. The
files are available in the
“AdditionalFiles – GSD”
folder in the STEP 7 project.
When opening the project,
the GSD file is installed
automatically.
ETS5 Demo
1
https://www.knx.org/kn
x-
en/software/ets/downl
oad/index.php
Maximum of 5 KNX devices
per project.
Sample files and projects
The following list contains all files and projects that are used in this example.
Table 2-5: Download files
Component
Note
109739689_KNX_DOC_V10_en.pdf
This document
109739689_KNX_S7_PROJ_V10.zip
This .zip file contains the
“MBS_KNX” STEP 7 project.
109739689_KNX_Gateway_RestoreFile_V10.zip
This zip file contains the
“ugwbackup.tgz” gateway
data backup with the
configuration files.
109739689_KNX_ETS5_PROJ_V10.zip
This .zip file contains the
ETS5 project.
