Connecting SCALANCE M-800 to WAN
1.2 Connecting M81x to ADSL
SCALANCE M-800 Getting Started
44 Getting Started, 06/2015, C79000-G8976-C337-04
3. Configure the firewall rule for HTTP with the following settings:
Action
Accept
From
Internal
To External
Source (Range)
192.168.100.10 (the required device)
Destination (Range) 0.0.0.0/0 (all addresses)
Service
HTTP
4. Click "Set Values".
5. Click "Create". A new entry is created in the table.
6. Configure the firewall rule for DNS with the following settings:
Action
Accept
From
Internal
To
Internal
Source (Range)
192.168.100.10 (the required device)
Destination (Range)
0.0.0.0/0 (all addresses)
Service
HTTP
7. Click "Set Values".
