Siemens SCALANCE XP-200 - Types of Installation; Wall Mounting

Installation
3.2 Types of installation
SCALANCE XP-200
Operating Instructions, 05/2016, C79000-G8976-C428-01
47
3.2
Types of installation
Types of installation
The SCALANCE XP-200 can be installed in the following ways:
● Wall mounting
● Wall mounting
● Rack mounting
3.3
Wall mounting
Note
Depending on the mounting surface, use suitable fittings.
Note
The wall mount
ing must be capable of supporting at least four times the weight of the device.
To mount the device on a wall, follow the steps below:
1. Prepare the drill holes for wall mounting. For the precise dimensions, refer to the section
"Dimension drawings".
2. Screw the device to the wall using the keyhole hang-up mechanisms.
3. Fit the connectors for the power supply, see the section "Power supply".
4. Fit the connectors for the signaling contact, refer to the section ""Signaling contacts".
