1 Introduction
VRRP
Entry-ID: 109798556, V1.0, 09/2021
10
© Siemens AG
2021 All rights reserved
Component
Item number
IP address and
subnet mask
Router
Note
SCALANCE
S615
6GK5 615-
0AA00-2AA2
Vlan 1:
192.168.1.3
255.255.255.0
Vlan 10:
192.168.10.3
255.255.255.0
VLAN 20:
192.168.20.3
255.255.255.0
Associated IP:
VRID 10:
192.168.10.1
255.255.255.0
VRID 20:
192.168.20.1
255.255.255.0
This firewall
backup is an
alternative to
the XM408
router.
This application example consists of the following components:
Table 1-2
Component
File name
Note
This document
109798556_VRRP_V1_0.en

Table of Contents
