Top view of the 100 to 240VAC / 110 to 250VDC device versions



Figure10-3 Depth
10.2 Mounting brackets for use on ships
You need special mounting brackets to install the device horizontally on a ship.
Below you will 󹪝nd the design drawing for making the mounting brackets.
You will 󹪝nd the more information on the construction of the mounting brackets in the
section "Technical speci󹪝cations (Page91)".
Note
ISO tolerance and punching burr
For dimensions without tolerance details, the general tolerances "medium" acc. to DIN ISO 2768
apply. No punching burrs are permitted.
Dimension drawings
10.2Mounting brackets for use on ships
