Device Properties Article number
SCALANCE XR522-12 24VAC/DC version
• 20 x 10 / 100 / 1000Mbps RJ45 ports
• 2 x 1 / 2.5 / 5 / 10 Gbps RJ45 ports
• 4 x SFP plug-in transceiver slots with 100 / 1000Mbps
• 8 x SFP / SFP+ plug-in transceiver slots with 1 / 10 Gbps
• 2 x 2-pin terminal block 24 V DC / 24 V AC, power supply connection
• 1 x CLP slot
• 1 x USB Type B, serial interface connection
• 1 x 2-pin terminal block 24VDC, signaling contact connection
6GK5534-3TR00-2AR3
100 to 240VAC / 110 to 250VDC version
• 20 x 10 / 100 / 1000Mbps RJ45 ports
• 2 x 1 / 2.5 / 5 / 10 Gbps RJ45 ports
• 4 x SFP plug-in transceiver slots with 100 / 1000Mbps
• 8 x SFP / SFP+ plug-in transceiver slots with 1 / 10 Gbps
• 1 x IEC plug (C14) 100 to 240 V AC, power supply connection, non-
redundant
• 1 x DC terminal block, 2-pin, 110 to 250VDC, power supply con‐
nection, non-redundant
• 1 x CLP slot
• 1 x USB Type B, serial interface connection
• 1 x 2-pin terminal block 24VDC, signaling contact connection
6GK5534-3TR00-3AR3
100 to 240VAC / 110 to 250VDC version
• 20 x 10 / 100 / 1000Mbps RJ45 ports
• 2 x 1 / 2.5 / 5 / 10 Gbps RJ45 ports
• 4 x SFP plug-in transceiver slots with 100 / 1000Mbps
• 8 x SFP / SFP+ plug-in transceiver slots with 1 / 10 Gbps
• 2 x IEC plug (C14) 100 to 240VAC, power supply connection,
redundant
• 2 x DC terminal block, 2-pin, 110 to 250VDC, power supply con‐
nection, redundant
• 1 x CLP slot
• 1 x USB Type B, serial interface connection
• 1 x 2-pin terminal block 24VDC, signaling contact connection
6GK5534-3TR00-4AR3
Description of the device
4.1Article numbers
SCALANCE XR-500
24 Operating Instructions, 07/2023, C79000-G8976-C692-01
