Siemens SCALANCE XR-500 User Manual

Technical speci󹪝cations
Permitted ambient conditions 
Ambient temperature
2)
Property Startup at -25°C
With LAN operation with RJ45 plug
Up to 2000 m above sea level
During operation in horizontal installation position:
-25 ℃ to +55 ℃
When operating with plug-in trans‐
ceivers of the standard version [-]
Up to 2000 m above sea level
During operation in horizontal installation position:
-25 ℃ to +55 ℃
When operating with plug-in trans‐
ceivers of the types
3)
:
• SFP992-1+
• LD+
• LH (except SFP993-1LH)
• LH+
• ELH
• ELH200
• BXMR
• BXMT
• BX10T
• BX10R
Up to 2000 m above sea level
During operation in horizontal installation position:
-25°C to +50°C
When operating with plug-in trans‐
ceiver SFP993-1LH
3)
Up to 2000 m above sea level
During operation in horizontal installation position:
-25°C to +40°C
With operation between 2000m
and 3000m above sea level
The maximum ambient temperature is reduced by
5°C
4)
During storage -40°C to +85°C
During transportation -40°C to +85°C
Relative humidity During operation at 25 ℃ ≤ 95% without condensation
Housing, dimensions and weight
Design Rack
Housing material Metal
Degree of protection IP20
5)
Dimensions (W x H x D) 446 x 43.5 x 384.8mm (1 height unit)
Weight Device version with one power sup‐
ply unit
8200 g 
Device version with two power sup‐
ply units
8400g 
Installation options
• 19" rack mounting
• Four-point mounting
Mounting restriction Operation with a DC terminal block only within a control cabinet
Conformal coating of the PCBs No
Design of the mounting bracket for four-point mounting
Dimensions (W x H x D) 43.6 x 43.6 x 18.3mm (1 height unit)
Technical speci󹪝cations
9.1SCALANCE XR502-32
SCALANCE XR-500
96 Operating Instructions, 07/2023, C79000-G8976-C692-01
