Technical specifications
8.3 X-300M technical specifications
SCALANCE X-300
164 Operating Instructions, 02/2012, A5E01113043-12
Table 8- 19 Permitted ambient conditions
Media module Storage/transport
temperature
Operating temperature
1)
Max. relative humidity
in operation at 25 °C
Max. ambient
temperature at operating
altitude
Without media module -40 °C to +70 °C Horizontal installation:
-40 °C to +70 °C
Vertical installation:
-40 °C to +50 °C
< 95 % (no
condensation)
Horizontal installation:
max. 65 °C as of 2 000 m
max. 60 °C as of 3 000 m
Vertical installation:
max. 45 °C as of 2 000 m
max. 40 °C as of 3 000 m
MM991-2,
MM991-2 (SC),
MM991-2LD,
MM991-2LD (SC),
MM992-2,
MM992-2LD,
MM992-2CU,
MM992-2CUC
-40 °C to +70 °C Horizontal installation:
-40 °C to +70 °C
Vertical installation:
-40 °C to +50 °C
< 95 % (no
condensation)
Horizontal installation:
max. 65 °C as of 2 000 m
max. 60 °C as of 3 000 m
Vertical installation:
max. 45 °C as of 2 000 m
max. 40 °C as of 3 000 m
MM991-2LH+ (SC),
MM992-2LH,
MM992-2LH+,
MM992-2ELH
-40 °C to +70 °C Horizontal installation:
-40 °C to +70 °C
Vertical installation:
-40 °C to +50 °C
< 95 % (no
condensation)
Horizontal installation:
max. 65 °C as of 2 000 m
max. 60 °C as of 3 000 m
Vertical installation:
max. 45 °C as of 2 000 m
max. 40 °C as of 3 000 m
MM992-2SFP and the
following SFP
transceivers:
SFP991-1.
SFP991-1LD,
SFP992-1.
SFP992-1LD
-40 °C to +70 °C Horizontal installation:
-40 °C to +60 °C
Vertical installation:
-40 °C to +50 °C
< 95 % (no
condensation)
Horizontal installation:
max. 55 °C as of 2 000 m
max. 50 °C as of 3 000 m
Vertical installation:
max. 45 °C as of 2 000 m
max. 40 °C as of 3 000 m
MM992-2SFP and the
following SFP
transceivers:
SFP991-1LH+,
SFP992-1LH,
SFP992-1LH+,
SFP992-1ELH
SFP991-1ELH200
-40 °C to +70 °C Horizontal installation:
-40 °C to +60 °C
Vertical installation:
-40 °C to +50 °C
< 95 % (no
condensation)
Horizontal installation:
max. 55 °C as of 2 000 m
max. 50 °C as of 3 000 m
Vertical installation:
max. 45 °C as of 2 000 m
max. 40 °C as of 3 000 m
1)
The permitted operating temperature depends on how the mounting device was installed. The installation is horizontal if
the device labeling is from left to right. With a vertical installation, the device labeling is rotated through 90°.
