Technical specifications
8.5 Technical specifications for X-300EEC
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
177
Table 8- 50 Mechanical stability
Strain withstood / category
(standard)
Test conditions
Vibration
(IEC 60068-2-6)
Frequency range 10 Hz to 150 Hz:
• Transit frequency: 58 Hz to 60 Hz
• Peak value of the displacement [mm] below the transit
frequency: 0.075
• Peak value of the acceleration [g] above the transit
frequency: 1
• Number of cycles per axis: 20
Frequency range 5 Hz to 150 Hz:
• Transit frequency: 8.4 Hz
• Peak value of the displacement [mm] below the transit
frequency: 3.5
• Peak value of the acceleration [g] above the transit
frequency: 1
• Number of cycles per axis: 10
• Octaves / min: 1
Frequency range 2 Hz to 100 Hz:
• Frequency range: 2 Hz to 100 Hz
• Transit frequency: 13.2 Hz
• Peak value of the displacement [mm] below the transit
frequency:1
• Peak value of the acceleration [g] above the transit
frequency: 0.7
• Number of cycles per
Vibration
(IEEE1613 Class V.S.2)
• Velocity: <10 mm/s
• Frequency: 1 to 150 Hz
Shock
(IEC 60068-2-27)
• Acceleration: 15 g
• Duration of the pulse: 11 ms
• Number of shocks per direction: 3
