Technical specifications
8.6 XR-300M EEC technical specifications
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
187
Table 8- 72 Electrical data: Overcurrent protection
Device version
(power supply)
Overcurrent protection of the power supply
Non-replaceable fuse
1 x 24 to 48 VDC 1 x T2H / 250 V
2 x 24 to 48 VDC 2 x T2H / 250 V
1 x 100 to 240 VAC /
60 to 250 VDC
1 x T2H / 250 V (AC)
1 x T2H / 300 V (DC)
2 x 100 to 240 VAC /
60 to 250 VDC
2 x T2H / 250 V (AC)
2 x T2H / 300 V (DC)
Table 8- 73 Electrical data: Signaling contact
Device version
(power supply)
Voltage via signaling contact Switching capacity
(resistive load)
24 to 48 VDC 24 VDC max. 0.1 A
240 VAC max. 5 A
60 VDC max. 0.4 A
125 VDC max. 0.22 A
100 to 240 VAC /
60 to 250 VDC
250 VDC max. 0.11 A
Table 8- 74 Plug-in terminal block for connectors of the power supply and signaling contact
Device version
(power supply)
Power supply Signaling contact
1 x 24 to 48 VDC 1 x 4-pin 1 x 2-pin
2 x 24 to 48 VDC 2 x 4-pin 2 x 2-pin
1 x 100 to 240 VAC /
60 to 250 VDC
1 x 3-pin 1 x 3-pin
2 x 100 to 240 VAC /
60 to 250 VDC
2 x 3-pin 2 x 3-pin
Table 8- 75 Overvoltage category
General Overvoltage category II
In the application range of EN 60255-27 Overvoltage category III
