Description of the device
4.2 Product groups
SCALANCE X-300
Operating Instructions, 02/2012, A5E01113043-12
67
Ports of the X302-7EEC
The SCALANCE X302-7EEC has the following ports:
● 2 electrical gigabit ports (P8 to P9)
● 7 optical Fast Ethernet ports (P1 to P7)
Figure 4-19 SCALANCE X302-7EEC
Port number P1 P2 P3 P4 P5 P6 P7 P8 P9
Connection type Optical
Fast Ethernet
Electrical
Gigabit Ethernet
