Connecting
5.6 Out-of-band interface
SCALANCE XR-500
68 Operating Instructions, 05/2017, A5E03275845-11
Assignment of the terminal block
The supplied connecting cable has the following assignment:
Contact
Pin assignment of the RJ-11 plug
Pin assignment of the D-sub female con-
nector
1
-
-
2 - TD (Transmit Data)
3
TD (Transmit Data)
RD (Receive Data)
4 SG (Signal Ground) -
5
RD (Receive Data)
SG (Signal Ground)
6
-
-
7
-
8
-
9
-
Note
Pin assignment of the RJ-11 jack on the device
The RJ
-11 jack on the device has a pinout to match the RJ-11 plug of the supplied
connecting cable.
5.6
Out-of-band interface
Information on the out-of-band interface
● The out-of-band interface is an RJ-45 Ethernet port on the CPU module. The out-of-band
interface is not used for routing or switching.
● Access to the device is also possible independent of the other Ethernet ports.
● The out-of-band interface allows direct IP access to the WBM of the device.
