Description of the device
3.1 Product overview
SCALANCE XR-500
18 Operating Instructions, 05/2017, A5E03275845-11
Device
Properties
Article number
Firmware
version
1 height unit, 2 SFP+ slots, 2 x 100 to 240 VAC, connector for the
power supply on the rear, layer 3 integrated
6GK5 526-8GR00-4AR2 V4.3
XR528-6M
2 height units, 4 SFP+ slots, 6 modules, layer 3 with KEY-PLUG
6GK5 528-0AA00-2AR2
as of V1.0
2 height units, 4 SFP+ slots, 6 modules, cable outlet at rear, layer 3
with KEY-PLUG
6GK5 528-0AA00-2HR2 as of V1.0
2 height units, 4 SFP+ slots, 6 modules, layer 3 integrated
6GK5 528-0AR00-2AR2
as of V1.0
2 height units, 4 SFP+ slots, 6 modules, cable outlet at rear, layer 3
integrated
6GK5 528-0AR00-2HR2 as of V1.0
XR552-12M
3 height units, 4 SFP+ slots, 12 modules, layer 3 with KEY-PLUG
6GK5 552-0AA00-2AR2
as of V1.0
3 height units, 4 SFP+ slots, 12 modules, cable outlet at rear, layer
3 with KEY-PLUG
6GK5 552-0AA00-2HR2 as of V1.0
3 height units, 4 SFP+ slots, 12 modules, layer 3 integrated
6GK5 552-0AR00-2AR2
as of V1.0
3 height units, 4 SFP+ slots, 12 modules, cable outlet at rear, layer
3 integrated
6GK5 552-0AR00-2HR2 as of V1.0
*
)
With the SCALANCE XR526-8C (2 x 24 VDC) if you use SFP/SFP+ pluggable transceivers
in the SFP+ slots, the maximum ambient temperature is reduced to 60 °C, see section
"Permitted ambient temperature (Page 19)".
Interfaces
Device
Total usa-
ble ports
Number of slots for
media modules
Modular ports
using module
slots
Pluggable trans-
ceiver slots
Electrical
connectors
Combo ports
SFP
SFP+
XR524-8C
24
-
-
8
-
24
8
XR526-8C
26
-
-
8
2
24
8
XR528-6M
28
6
24
-
4
-
-
XR552-12M
52
12
48
-
4
-
-
Components of the product
The following components ship with a SCALANCE XR-500:
SCALANCE
XR524-8C
SCALANCE
XR526-8C
SCALANCE
XR528-6M
SCALANCE
XR552-12M
Device with exchangeable medi-
um C-PLUG
● ● ● ●
Product DVD with documentation
and software
● ● ● ●
2 brackets for 19" rack installa-
tion
● ● ● ●
8 screws for mounting the fixing
brackets for 19" rack installation
M3 x 5 countersunk,
Drive: Torx
M3 x 5 countersunk,
Drive: Torx
M3 x 6 countersunk,
Drive: Torx
M3 x 6 countersunk,
Drive: Torx
4 adhesive feet for desktop oper-
ation
● ● ● ●
