8.4
Technical specifications of the SCALANCE XR552-12M
The following technical specifications apply to the SCALANCE XR552-12M.
Technical specifications
Attachment to Industrial Ethernet
Slots for media modules
Quantity
12
Slots for SFP transceivers (SFP+)
Quantity
4
Connector
SFP transceivers (LC port)
Transmission speed
10 Gbps
Diagnostics interface
Serial interface
Quantity
1
Connector
RJ-11 jack
Out-of-band interface
Quantity
1
Connector
RJ-45 jack
Signaling contact
Quantity
1
Design
Terminal block, 2 terminals
Permitted voltage range
24 VDC
Load capability
max. 100 mA
Connection to power supply
24 VDC power supply
Design
Terminal block, 4 terminals
Rated voltage
24 VDC
Voltage range
19.2 VDC - 28.8 VDC
Fusing
3.15 A / 125 V
Cable cross-section
• Minimum
• Maximum
• 0.75 mm
2
(18 AWG)
• 2.5 mm
2
(12 AWG)
Properties
Implemented redundantly
Connector for power supply unit
PS598-1
Quantity
2
Design
Terminal block
Overcurrent protection of the power
supply
Non-replaceable fuse
Fan unit T 5 A / 125 V
Electronics F 15 A / 125 V
PoE
F 15 A / 125 V
Electrical data (basic device without media modules)
24 VDC power supply
Current consumption
1.42 A
Effective power loss
34.08 W
Electrical data (basic device with maximum device configuration)
24 VDC power supply
Current consumption
12.5 A
Effective power loss 300 W
Permitted ambient conditions
