Description of the device
3.1 Product overview
SCALANCE XR-500
22 Operating Instructions, 05/2017, A5E03275845-11
SFP992-1LH 1 x 1000 Mbps LC port optical for glass FO
cable (single mode) up to max. 40 km
6GK5 992-1AN00-8AA0
SFP992-1LH+ 1 x 1000 Mbps LC port optical for glass FO
cable (single mode) up to max. 70 km
6GK5 992-1AP00-8AA0
SFP992-1ELH 1 x 1000 Mbps LC port optical for glass FO
cable (single mode) up to max. 120 km
6GK5 992-1AQ00-8AA0
* Cannot be operated in SFP+ slots.
Pluggable transceivers with the supplement (C) in the type name have varnished printed circuit boards
(conformal coating).
Note
Restriction for pluggable transceivers for SCALANCE XR524-8C (2 x 24 VDC) and
SCALANCE XR526-8C (2 x DC 24 V)
If you use pluggable transceivers of the types LH, LH+, ELH or ELH200 wit
h a SCALANCE
-8C (2 x 24 VDC) and SCALANCE XR526-8C (2 x 24 VDC) , the maximum ambient
temperature is reduced to 60
℃.
For further information on the ambient temperature, refer to sections “
Permitted ambient
(Page 19)“ and “Technical data (Page 83)“.
Note
No far-end fault detection for an SFP transceiver in SFP+ slots with SCALANCE XR528 and
SCALANCE XR552
If you use an SFP transceiver in
an SFP+ slot, no far-end fault detection is possible for this
interface. This can impair the functionality of link
-based protocols, e.g. ring redundancy.
SFP993-1 1 x 10 Gbps, LC port optical for glass FO
cable (multimode), up to max. 300 m
6GK5 993-1AT00-8AA0
1)
1 x 10 Gbps, LC port optical for glass FO
cable (multimode), up to max. 300 m
6GK5 993-1AT10-8AA0
2)
SFP993-1LD 1 x 10 Gbps, LC port optical for glass FO
cable (single mode), up to max. 10 km
6GK5 993-1AU00-8AA0
1)
1 x 10 Gbps, LC port optical for glass FO
cable (single mode), up to max. 10 km
6GK5 993-1AU10-8AA0
2)
SFP993-1LH 1 x 10 Gbps, LC port optical for glass FO
cable (single mode), up to max. 40 km
6GK5 993-1AV00-8AA0
1)
Can only be operated in SFP+ slots.
