2 Abridged checklist
Checklist
Article ID: 109745536, V2.0, 05/2022
7
© Siemens AG
2022 All rights reserved
2 Abridged checklist
Check the following steps for each SCALANCE device:
• Use the latest firmware
• Disable "http" and use "https" instead
• Change default passwords for the users "admin" and "user"
• Disable "Telnet" and use "ssh" for the CLI instead
If not using CLI, disable "Telnet" and "ssh"
• Restrict DCP access to read-only
• Restrict SNMPv1/2 to read-only access at minimum, use of SNMP V3 is
preferred
• Use at least TLS version V1.2 / SFTP instead of TFTP / Syslog with TLS
• Switch off option 66, 67 for DHCP client
• Disable PROFINET interface if not using PROFINET
• Enable time synchronization
• With SCALANCE X, disable preset ring ports
• Disable "spanning tree" if it is not needed
• Disable the option "SINEMA Configuration Interface"
• If PROFINET data traffic is running over the device and no custom VLAN
configuration is being used, then enable "VLAN 0 aware mode"
(X-300) or "802.1D Transparent Bridge"
• Enable WLAN encryption and use WPA2
• Set the default gateway in all devices
If a gateway is not being used, still set the gateway address to an unused IP
address in the local network
• Create a configuration backup via WBM or C-Plug
Note
Not all of the features described above are available on all SCALANCE devices.
The features available depend on the SCALANCE model and the firmware
version you are using.

Siemens SCALANCE Specifications

General

Product Family	SCALANCE
Function	Ethernet Switch
Temperature Range	-40°C to +70°C (depending on model)
Protection Class	IP20, IP30 (depending on the model)
Mounting	DIN rail, wall mounting (depending on the model)
Power Supply	24 V DC
Number of Ports	Varies by model (e.g., 4, 8, 24 ports)
Type	Managed, Unmanaged
Subtypes	X, W, M, S
Certifications	CE, ATEX, IECEx (depending on the model)
Network Protocols	PROFINET, Ethernet
