Siemens SIGMASYS M User Manual

14 Order Overview
Name Order number Remark
SIGMASYS C Bestellübersicht
SIGMASYS C control and indicating
panel
S24230-C500-A7
Control and indicating panel without operat-
ing panel with power supply unit (PSU) 150
W and without battery
SIGMASYS C Sinteso control and in-
dicating panel
S24230-C600-A10
Control and indicating panel without operat-
ing panel
SIGMASYS C Foil for operating panel S24230-F515-A2
Operating panel for SIGMASYS C control
and indicating panel
SIGMASYS C dummy plate C24230-A13-C54 For SIGMASYS C without operating panel
Battery 12V 25 Ah GBI: 13013 For installation in SIGMASYS C
Battery 12V 65 Ah V24069-Z103-A7
For installation in SIGMASYS battery cabi-
net
SIGMASYS Battery cabinet
SIGMASYS M
S24230-C109-A1 Battery cabinet for 2 x 12 V / 65 Ah batteries
SIGMASYS M Bestellübersicht
SIGMASYS M control and indicating
panel
S24230-C107-A6 Basic unit with SV 150W , SAC and SOC
without operating panel, without line mod-
ules, upgradable with the following options
SIGMASYS M control and indicating
panel
S24230-C107-A7 Basic unit with SV 150W , SAC
without SOC, operating panel, without line
modules, upgradable with the following op-
tions
SIGMASYS SOC S24230-A100-A4
Standard processor module with
SIGMANET
SIGMASYS SOC P S24230-B60-A Performance processor module
SIGMASYS APL 20 P S24230-B70-A1 SOC P Interface connection board
Crossover Ethernet cable A5Q00019146 For dual SOC operation
FN2001-D1 Netmodule (SAFEDLINK) A5Q00020525 for SOC P / SIGMANET P network
SAFEDLINK Repeater S24236-B2502-A1 SIGMANET P extensiom
SIGMANET operating panel S24230-F130-A4
Operating panel for installation in
SIGMASYS M control and indicating panel,
OP-housing, OP console installation
SIGMASYS M dummy plate C24230-A12-B17
Dummy plate for SIGMASYS M in remote
operating panel
SIGMASYS Battery cabinet OP hous-
ing remote
S24230-C109-A1 Battery cabinet für 2 x 12V 65Ah batteries
SIGMASYS FDnet Ansch. FDC S24230-B150-A1 Sinteso
TM
detector Loop connection
SIGMASYS MPC S24230-B103-A6 SIGMASYS detector Loop connection
SIGMASYS GMG-S S24230-A106-A2 Threshold detector connection
SIGMASYS PMG-S S24230-A105-A1 Pulse-polling detector connection
SIGMASYS APL 26 S24230-A122-A1 Connection board for PMG-S
SIGMASYS APL 20 S24230-A123-A2 Connection board for MPC
SIGMASYS U-APL S24230-A133-A1 Connection board for dual-MPC/FDC
SIGMASYS LPC Anschaltung S24230-B139-A1 Transliner Ringbus connection
TR-APL S24230-A145-A1 Connection board for LPC
Additional equipment for SIGMASYS C and M
Operating panels
GMA-BF DT1000 / CF L24236-P38-A1
Operating panel remote S24230-C119-A2
Operating panel housing for console and
wall mounting incl. cover plate
DT1000 OP console, tiltable C24230-A18-A2 DT1000 OP console, tiltable
Operating panel cover C24230-A16-B16 Operating panel cover
104 / 128 BMT Project Planning Guidelines
Best.Nr. A24205-A337-B970 – Edition 12 (03/07)
